$$\begin{array}{l} From\, the\, figure \\ Equation\, of\, line\, AB \\ y-{ y_{ 1 } }=\dfrac { { { y_{ 2 } }-{ y_{ 1 } } } }{ { { x_{ 2 } }-{ x_{ 1 } } } } \left( { x-{ x_{ 1 } } } \right) \\ P-{ P_{ 0 } }=\dfrac { { 2{ P_{ 0 } }-{ p_{ 0 } } } }{ { { V_{ 0 } }2{ V_{ 0 } } } } \left( { V-2{ V_{ 0 } } } \right) \\ =\dfrac { { -{ P_{ 0 } } } }{ { { V_{ 0 } } } } \left( { V-2{ V_{ 0 } } } \right) \\ P=\dfrac { { -{ P_{ 0 } } } }{ { { V_{ 0 } } } } V+3{ P_{ 0 } } \\ PV=-\dfrac { { { P_{ 0 } } } }{ { { V_{ 0 } } } } V+3{ P_{ 0 } }V \\ nRT=-\dfrac { { { P_{ 0 } } } }{ { { V_{ 0 } } } } V+3{ P_{ 0 } }V \\ T=\dfrac { 1 }{ { nR } } \left( { -\dfrac { { { P_{ 0 } } } }{ { { V_{ 0 } } } } V+3{ P_{ 0 } }V } \right) \\ \dfrac { { dT } }{ { dV } } =0\, \, \left( { for\, \max imum\, temperature } \right) \\ -\frac { { { P_{ 0 } } } }{ { { V_{ 0 } } } } 2V+3{ P_{ 0 } }=0 \\ -\dfrac { { { P_{ 0 } } } }{ { { V_{ 0 } } } } 2V=-3{ P_{ 0 } } \\ V=\dfrac { 3 }{ 2 } { V_{ 0 } }\, \, \left( { condition\, for\, \max imum\, \, temperature } \right) \\ { T_{ \max } }=\dfrac { 1 }{ { nR } } \left( { \dfrac { { { P_{ 0 } } } }{ { { V_{ 0 } } } } \times \dfrac { 9 }{ 4 } V_{ 0 }^{ 2 }+3{ P_{ 0 } }\times \frac { 3 }{ 2 } { V_{ 0 } } } \right) \\ =\frac { 1 }{ { nR } } \left( { -\dfrac { 9 }{ 4 } { P_{ 0 } }{ V_{ 0 } }+\dfrac { 9 }{ 2 } { P_{ 0 } }{ V_{ 0 } } } \right) \\ =\dfrac { 9 }{ 4 } \dfrac { { { P_{ 0 } }{ V_{ 0 } } } }{ { nR } } \end{array}$$
Hence, the option $$B$$ is the correct answer.
