Solid State Test

Result

Solid State Test - 77

Score
-
out of -
Rank
-
out of -

TIME Taken - -

SHARING IS CARING

If our Website helped you a little, then kindly spread our voice using Social Networks. Spread our word to your readers, friends, teachers, students & all those close ones who deserve to know what you know now.

Weekly Quiz Competition

Question 1
1 / -0

A compound has a BCC unit cell with an edge length of 10A. If the density is 2 $$g/cm^{3}$$ then the molar mass of the compound is

A
600

B
300

C
350

D
250

Solution
Question 2
1 / -0

CCP is also called as :

A
FCC

B
BCC

C
Primitive

D
HCP

Solution
Question 3
1 / -0

Sodium crystallises in bcc arrangement with the interfacial sepration between the atoms of the edge $$53 pm$$. The density of the solid is :

A
$$1.23 g/cc$$

B
$$485 g/cc$$

C
$$4.85 g/cc$$

D
$$123 g/cc$$
Question 4
1 / -0

Select the correct statement related to hexagonal close packing of identical spheres in three dimensions.

A
In one unit cell, there are 12 octahedral voids and all are completely inside the unit cell.

B
In one unit cell, there are six octahedral voids and all are completely inside the unit cell.

C
The number of atoms per unit cell in hcp are 12

D
Coordination number of every sphere is 8

Solution
Question 5
1 / -0

In a cubic lattice if atoms are present only at all the corners and alternate face centres then the packing efficiency will be:

A
$$74 \%$$

B
$$37\%$$

C
$$68\%$$

D
Cannot be determined

Solution
Question 6
1 / -0

Edge length is 200$$\mathrm { pm }$$ in body-centred unit cell what will be the radius of atom in pm?

A
139

B
150

C
86.6

D
93.4

Solution
Question 7
1 / -0

Crystals of different ionic compounds having similar arrangement of ions as well as geometry are known:

A
Isomorphs

B
Isomers

C
Anomers

D
Isotopes
Question 8
1 / -0

Which of the following is the only incorrect statement regarding amorphous solids?

A
On heating, they may become crystalline at some temperature

B
They may become crystalline on keeping for long time

C
Amorphous solids can be molded by heating

D
They are anisotropic in nature

Solution
Question 9
1 / -0

A lattice is defined as

A
the amount of energy required, per mole, to separate the ions from their lattice positions to an infinte distance in the gas phase

B
the distance separating the cations and anions

C
a set of all points with identical environments within crystal

D
the arrangement of electrons in various energy levels

Solution
Question 10
1 / -0

What is the packing efficiency of arrangement in a body centred unit cell?

A
$$53.26\%$$

B
$$74.00\%$$

C
$$68.00\%$$

D
$$64.00\%$$

Solution

Packing efficiency is defined as the percentage of space occupied by constituent particles packed inside the lattice.
Consider edge length is $$a$$
In BCC,
$$AC=\sqrt{AB^2+BC^2}=\sqrt{a^2+a^2}=\sqrt2 a$$

$$AC=FD$$

and $$AF=\sqrt{AD^2+FD^2}=\sqrt{2a^2+a^2}=\sqrt{3}a$$

Thus $$\sqrt3 a=4r$$ i.e., $$a=\dfrac{4r}{\sqrt3}$$
Volume of the unit cell=$$a^3=\left(\dfrac{4r}{\sqrt3}\right)^3=\dfrac{64r^3}{3\sqrt3}$$
Now, No. of spheres per unit cell=$$8\times \dfrac18+1=1+1=2$$
Thus volume of two spheres=$$2\times \dfrac43 \pi r^3=\dfrac83 \pi r^3$$
$$\therefore \text{Packing efficiency}=\dfrac{\dfrac83 \pi r^3}{\dfrac{64}{3\sqrt3}r^3}=0.68$$
Thus, $$\%\text{Packing efficiency}=68\%$$
