Question 1
1 / -0

In a series $$LCR\, AC$$ circuit, the current is maximum when the impedance is equal to:

A
the reactance

B
the resistance

C
zero

D
twice the reactance

E
twice the resistance

Solution

In L-C-R circuit, the current
$$I=\displaystyle\frac{E_0}{\sqrt{R^2+(X_L-X_C)^2}}$$
When impedance $$Z=R$$, i.e., $$X_L=X_C$$ the current in the L-C-R circuit will be maximum.
Question 2
1 / -0

In an oscillating system, a restoring force is a must. In an L-C circuit, the restoring force is provided by a/an

A
inductor

B
capacitor

C
resistor

D
both A and B

Solution
Question 3
1 / -0

Alternating current is flowing in inductance $$L$$ and resistance $$R$$. The frequency of source is $$\omega/2\pi$$ Which of the following statement in correct:

A
For low frequency the limiting value of impedance is $$L$$.

B
For high frequency the limiting value of impedance is $$\omega L$$.

C
For high frequency the limiting value of impedance is $$R$$.

D
For low frequency the limiting value of impedance is $$\omega L$$.

Solution
Question 4
1 / -0

If we increase the driving frequency in a circuit with a purely resistive load, then amplitude $$V_R$$

A
remain in the same

B
increase

C
decrease

D
none

Solution

We know that $$V_R$$ does not depend on driving frequency in a purely resistive circuit.So,If we increase the driving frequency in a circuit with a purely resistive load, then amplitude remain in the same.
Therefore, A is correct option.
Question 5
1 / -0

The ratio of peak value and r.m.s value of an alternating current is

A
$$ 1 $$

B
$$ \dfrac{1}{2} $$

C
$$ \sqrt{2} $$

D
$$ \dfrac{1}{\sqrt{2}} $$

Solution

As we know,
$$V_0=V_{rms} \times \sqrt 2$$
so,
$$\dfrac{V_0}{V_{rms}}=\sqrt 2$$
Question 6
1 / -0

Current in the circuit is wattless, if

A
Inductance in the circuit is zero

B
Resistance in the circuit is zero

C
Current is alternating

D
Resistance and inductance both are zero

Solution

Current in the circuit is wattless,
Because power = $$ i^2R $$ , if $$ R = 0 $$ , then $$ P = 0 $$.
Question 7
1 / -0

The power factor of L-R circuit is :

A
$$\dfrac{R}{\omega L}$$

B
$$\dfrac{R}{(\omega L)^2+R^2}$$

C
$$\omega LR$$

D
$$\sqrt{\omega LR}$$

Solution
Question 8
1 / -0

Statement A: With an increase in the frequency of AC supply inductive reactance increases.
Statement B: With an increase in the frequency of AC supply capacitive reactance increase.

A
A is true but B is false

B
Both A and B are true

C
A is false but B is true

D
Both A and B are false

Solution

$$Z_L=WL$$ $$Z_C=\dfrac{1}{wc}$$

$$w\uparrow, Z_L\uparrow Z_c\downarrow$$
Question 9
1 / -0

In series L-C-R resonant circuit, to increase the resonant frequency :

A
L will have to be increased

B
C will have to be increased

C
LC will have to be decreased

D
LC will have to be increased

Solution

Resonant frequency $$=\dfrac{1}{\sqrt{LC}}$$

$$LC \downarrow \ if \ \omega_r \uparrow$$
Question 10
1 / -0

At low frequency a condenser offers :

A
high impedance

B
low impedance

C
zero impedance

D
impedance of condenser is independent of frequency

Solution

$$Z=\dfrac{1}{wc}$$

$$w\downarrow Z\uparrow$$
