Control Systems Test 2

Question 1
2 / -0.33

Consider the polynomial

P(s) = s⁵ + 5s⁴ + 11s³ + 23s² + 28s + 12

Using the Routh Hurwitz criteria, which of the following is/are true?

A
The system has no roots on the imaginary axis

B
The system has multiple roots at the origin

C
The system is stable

D
The system has three poles on the left half of s-plane

Question 2
2 / -0.33

The open-loop transfer function of a unity feedback system is given by
\(G\left( s \right) = \frac{{10}}{{s\left( {\frac{s}{5} + 1} \right)\left( {\frac{s}{{20}} + 1} \right)}}\)
In G(s) plane, the Nyquist plot of G(s) passes through the negative real axis at the point

A
(-0.4, 0)

B
(-2.5, 0)

C
(-4, 0)

D
(-0.25, 0)

Question 3
2 / -0.33

A unity feedback control system has an open-loop transfer function
\(G\left( s \right) = \frac{A}{{s\left( {s + a} \right)}}\)
The sensitivity of the closed-loop transfer function to the changes in the parameter is

A
\(\frac{{ - A}}{{{{\left( {s + a} \right)}^2}}}\)

B
\(\frac{{ - a}}{{\left( {s + a} \right)}}\)

C
\(\frac{{ - As}}{{{{\left( {{s^2} + as + A} \right)}^2}}}\)

D
\(\frac{{ - as}}{{\left( {{s^2} + as + A} \right)}}\)

Question 4
2 / -0.33

The system matrix of a continuous time system, described in the state variable from is
\(\left[ {\begin{array}{*{20}{c}}x&0&0\\0&y&{ - 1}\\0&1&{ - 2}\end{array}} \right]\)
The range of x and y so that the system is stable is

A
x > 0, y > 2

B
x < 0, y < 0.5

C
x < 0, y > 2

D
x > 0, y < 0.5

Question 5
2 / -0.33

A system is represented by the following equation
\(\ddot y\left( t \right) + 6\dot y\left( t \right) + 5y\left( t \right) = u\left( t \right)\)
For the unit response of the system, the steady state value of the output is _______

A
0.2-0.2

B
0.24-0.21

C
0.27-0.26

D
0.29-0.22

Question 6
2 / -0.33

The transfer function of a control system is given by
\(\frac{{C\left( s \right)}}{{R\left( s \right)}} = \frac{{25}}{{{s^2} + 6s + 25}}\)
The first maximum value of the response occurs at a time t_max given by

A
\(\frac{\pi }{8}\)

B
\(\frac{\pi }{4}\)

C
\(\frac{\pi }{2}\)

D
π

Question 7
2 / -0.33

For the transfer function, \(G\left( s \right) = \frac{{5\left( {s + 4} \right)}}{{s\left( {s + 0.25} \right)\left( {{s^2} + 10s + 25} \right)}}\), the values of the constant gain term and the highest corner frequency of the Bode plot respectively are:

A
3.2, 5.0

B
16.0, 4.0

C
3.2, 4.0

D
16.0, 5.0

Question 8
2 / -0.33

Consider the open-loop transfer function \(G\left( s \right)H\left( s \right) = \frac{K}{{s\left( {{s^2} + 6s + 25} \right)}}\). The angle of departure at the complex pole with positive imaginary part (angle measured in the anticlockwise direction and to be answered in between 0 and 360) in degrees is _______

A
319-327

B
3194-3271

C
3197-3276

D
3199-3272

Question 9
2 / -0.33

A certain linear time invariant system has the state and the output equations given below
\(\left[ {\begin{array}{*{20}{c}}{{{\dot x}_1}}\\{{{\dot x}_2}}\end{array}} \right] = \left[ {\begin{array}{*{20}{c}}1&{ - 1}\\0&1\end{array}} \right]\left[ {\begin{array}{*{20}{c}}{{x_1}}\\{{x_2}}\end{array}} \right] + \left[ {\begin{array}{*{20}{c}}0\\1\end{array}} \right]u\)
\(y = \left[ {1\;\;1} \right]\left[ {\begin{array}{*{20}{c}} {{x_1}}\\ {{x_2}} \end{array}} \right]\)
If \(\left[ {\begin{array}{*{20}{c}} {{x_1}\left( 0 \right)}\\ {{x_2}\left( 0 \right)} \end{array}} \right] = \left[ {\begin{array}{*{20}{c}} 1\\ { - 1} \end{array}} \right]\)and u(0) = -1, then \(\frac{{dy}}{{dt}}\;at\;t = 0\) is ______

A
0-0

B
04-01

C
07-06

D
09-02

Question 10
2 / -0.33

Consider a plant whose transfer function is \(\frac{2}{{s\left( {s + 4} \right)}}\). It is desired that a lead compensator is used to design a negative feedback closed loop system with this plant.
The lead compensator needs to provide a maximum phase lead of 40° and this maximum phase lead angle should be provided at a frequency of 5 rad/sec.
It is desired that the static velocity error constant of the compensated system to be 10.
Then the transfer function of the lead compensator is

A
\({G_c}\left( s \right) = \frac{{93\left( {s + 2.3} \right)}}{{\left( {s + 10.7} \right)}}\)

B
\({G_c}\left( s \right) = \frac{{10\left( {s + 10.7} \right)}}{{\left( {s + 2.3} \right)}}\)

C
\({G_c}\left( s \right) = \frac{{10\left( {s + 2.3} \right)}}{{\left( {s + 10.7} \right)}}\)

D
\({G_c}\left( s \right) = \frac{{93\left( {s + 10.7} \right)}}{{\left( {s + 2.3} \right)}}\)

Question 11
2 / -0.33

The unity feedback system has forward path transfer function.
\(G\left( s \right) = \frac{K}{{s\left( {s + 1} \right)\left( {s + 2} \right)}}\)
What is the maximum value of K that will make its gain margin zero?

A
6-6

B
64-61

C
67-66

D
69-62
