Question 1
1 / -0

A thermodynamics cycle takes in heat energy at a high temperature and rejects energy at a lower temperature. If the amount of energy rejected at the low temperature is 3 times the amount of work done by the cycle, the efficiency of the cycle is:

A
$$0.25$$

B
$$0.33$$

C
$$0.67$$

D
$$0.9$$

Solution

Let heat taken be $$ Q_1$$, heat rejected be $$Q_2$$, and work done be W
Then $$Q_2=3W$$
Also, $$Q_1=Q_2 + W$$
$$\Rightarrow Q_1=4W$$
Efficiency of cycle=work done/heat taken=$$\dfrac{W}{4W}=\dfrac{1}{4}=0.25$$
Question 2
1 / -0

Monoatomic , diatomic and triatomic gases whose initial volume and pressure are same , are compressed till their volume becomes half the initial volume.

A
If the compression is adiabatic then the monoatomic gas will have maximum final pressure

B
If the compression is adiabatic then triatomic gas will have maximum final pressure

C
If the compression is adiabatic then their final pressure will be same.

D
If the compression is isothermic then final pressure will be different

Solution

For an adiabatic process,
$$ {P} {V}^{\gamma} = constant $$
or
$$\dfrac{P_1}{P_2}=(\dfrac{V_2}{V_1})^{\gamma}$$
or
$$P_2=2^{\gamma}P_1$$
Now, for a monoatomic gas, the value of $$ \gamma $$ is the highest
Thus, for the same change in volume, the monoatomic gas will have the maximum pressure.
Question 3
1 / -0

A reversible adiabatic path on a P-V diagram for an ideal gas passes through sate A where $$ P=0.7 \times 10^5 N/{m}^{-2} $$ and $$v=0.0049\ m^3$$. The ratio of specific heat of the gas is 1.4 . The slope of path at A is:

A
$$2.0 \times 10^7 N{m}^{-5} $$

B
$$1.0 \times 10^7 N{m}^{-5} $$

C
$$-2.0 \times 10^7 N{m}^{-5} $$

D
$$-1.0 \times 10^7 N{m}^{-5} $$

Solution

For reversible adiabat,
$$Pv^\gamma=constant \Rightarrow vdP + P\gamma dv=0 \Rightarrow \dfrac{dP}{dv}=-\dfrac{\gamma P}{v}$$
For $$P=0.7 \times 10^5Nm^{-2}, v=0.0049m^3, \gamma =1.4$$
required slope= $$-\dfrac{1.4\times 0.7\times 10^5\ Nm^{-2}}{0.0049\ m^3}=-2\times 10^7Nm^{-5}$$
Question 4
1 / -0

$$1\ kg $$ of gas does $$20\ kJ$$ of work and receives $$16\ kJ$$ of heat when it is expanded between two states. A second kind of expansion can be found between the initial and final state which requires a heat input of $$9\ kJ$$. The work done by the gas in the second expansion is:

A
$$32\ kJ$$

B
$$5\ kJ$$

C
$$-4 kJ$$

D
$$13\ kJ$$

Solution

The change in the internal energy will remain the same, since the initial and final states are the same for both the processes.
Thus, U = Q - W
16 - 20 = 9 - W
$$W = 13\ kJ$$
Question 5
1 / -0

On an isothermal process, there are two POINTs $$A$$ and $$B$$ at which pressures and volumes are $$(2P_o,\:V_o)$$ and $$(P_o,\:2V_o)$$ respectively. If $$A$$ and $$B$$ are connected by a straight line, the temperature of the isothermal process is how much lower the maximum temperature

A
$$\displaystyle\frac{P_oV_o}{nR}$$

B
$$\displaystyle\frac{P_oV_o}{2nR}$$

C
$$\displaystyle\frac{3P_oV_o}{2nR}$$

D
$$\displaystyle\frac{P_oV_o}{4nR}$$

Solution

Using symmetry, the temperature will be maximum at a point where the pressure and the volume attain the same value.
Therefore, on a straight line, joining the 2 points A and B as given in the question, the temperature will be maximum at their midpoint.
Hence, the pressure will be $$ \dfrac{3 {P}_{o}}{2} $$ and the volume will be $$ \dfrac{3 {V}_{o}}{2} $$
Thus, for n moles of a gas, the maximum temperature is,
$$ T = \dfrac{9 {P}_{o} {V}_{o}}{4nR} $$
However, the isothermal temperature is,
$$ T = \dfrac{2 {P}_{o} {V}_{o}}{nR} $$
Thus, the difference in 2 temperatures will be,
$$ \dfrac{{P}_{o} {V}_{o}}{4nR} $$
Question 6
1 / -0

A vessel contains an ideal monoatomic gas which expands at constant pressure, when heat $$Q$$ is given to it. What is the work done?

A
$$Q$$

B
$$\dfrac{3}{5}Q$$

C
$$\dfrac{2}{5}Q$$

D
$$\dfrac{2}{3}Q$$

Solution

For monoatomic gas,$$ C_p=\dfrac{5R}{2}, C_v=\dfrac{3R}{2}$$
Hence for isobaric process, heat given=$$Q=\dfrac{5}{2}nR\Delta T=\dfrac{3}{2}nR\Delta T + W$$
$$\Rightarrow W=nR\Delta T=\dfrac{2}{5}Q$$
Question 7
1 / -0

In an adiabatic process, $$\displaystyle R=\frac{2}{3}C_v$$. The pressure of the gas will be proportional to:

A
$$T^{5/3}$$

B
$$T^{5/2}$$

C
$$T^{5/4}$$

D
$$T^{5/6}$$

Solution

It is given that, $$ {C}_{v} = 1.5 R $$
Using, $$ {C}_{p} = {C}_{v} + R $$,
$$ {C}_{p} = 2.5 R $$
Thus, $$ \gamma = \dfrac{2.5}{1.5} = 5/3$$

Now,
Using the condition of adiabaticity,
$$ {P}^{1 - \gamma} {T}^{\gamma} = constant $$
Substituting the value of $$ \gamma $$ ,
Pressure is directly proportional to $$ {T}^{5/2} $$
Question 8
1 / -0

An ideal gas confined into an insulated chamber is allowed to enter into an evacuated insulated chamber. If Q,W and $$ \Delta E _{int} $$ have the usuak meanings, then

A
Q=0, W $$ \neq 0$$

B
W=0, Q $$ \neq 0$$

C
$$ \Delta E _{int} =0, Q \neq 0$$

D
$$Q=W, \Delta E _{int} =0$$

Solution
Question 9
1 / -0

Certain perfect gas is found to obey $$ P{V} ^{3/2} = constant $$ during an adiabatic process. If such a gas at initial temperature T is adiabatically compressed to half the initial volume, its final temperature will be

A
$$\sqrt{2}T$$

B
$$2T$$

C
$$2\sqrt{2} T$$

D
$$4T$$

Solution

Using the ideal gas law, P is directly proportional to $$ \dfrac{T}{V} $$
Substituting this value,
$$ T {V}^{0.5} = constant $$
Thus, when the volume is halved, we raise the temperature by $$ \sqrt 2 $$ times.
Question 10
1 / -0

One mol of a gas at NTP is suddenly expanded to three times its initial volume. If $$C_v =2 R$$, the ratio of initial to final pressure of gas will nearly be

A
$$5$$

B
$$4$$

C
$$3$$

D
$$2$$

Solution

$$P_1 V_1^{\gamma} = P_2 V_2^{\gamma}$$
$$P_2 = P_1 \displaystyle \left ( \dfrac{V_1}{V_2} \right )^{\gamma} = 1 \left ( \dfrac{1}{3} \right )^{3/2}$$
$$\displaystyle \dfrac{P_1}{P_2} = 3 \sqrt{3} =5.1$$
