Question 1
1 / -0

The amplitude of a wave disturbance propagating in the positive y-direction is given by:
$$y = \dfrac{1}{1 + x^2}$$ at $$ t = 0s \ and \ y = \dfrac{1}{1 + (x - 1)^2}$$ at $$ t = 2s$$, then wave velocity is

A
$$1 m/s$$

B
$$1.5 m/s$$

C
$$0.5 m/s$$

D
$$2 m/s$$

Solution

in $$2$$ sec the wave moves $$1$$m
$$\therefore$$Velocity $$ = \dfrac{1}{2}\,\,m/s$$.
$$\therefore$$ Option $$C$$ is correct.
Question 2
1 / -0

The light waves from two independent monochromatic light sources are given by-
$${y_1} = 2\sin {\omega t }$$ and $${y_2} = 2\cos {\omega t }$$,
then the following statement is correct

A
Both the waves are coherent

B
Both the waves are incoherent

C
Both the waves have different time periods

D
None of the above

Solution

$${y_1} = 2\sin \left( {\omega t - kx} \right)$$
$${y_2} = 2\cos \left( {\omega t - kx} \right) = 2\sin \left( {\omega t - kx + \frac{\pi }{2}} \right)$$
So, Phase difference = $$\frac{\pi}{2}$$
Hence sources are incoherent.
Question 3
1 / -0

The displacement of a particle executing S.H.M is given by $$x=0.25sin200t$$in meters.The maximum speed of particle is :

A
$$50m{s^{ - 1}}$$

B
$$25m{s^{ - 1}}$$

C
$$200m{s^{ - 1}}$$

D
$$100m{s^{ - 1}}$$

Solution

$$\begin{array}{l}{V_{\max }} = Aw\\when\,\cos wt = 1\\x = 0.25\cos \left( {200t} \right)\\{V_{\max }} = 0.25 \times 200 = 50m{s^{ - 1}}\end{array}$$
Question 4
1 / -0

The displacements of two interfering light waves are $$y_1 = 4 \ sin (\omega t) \ and \ y_2 = 3 \ cos (\omega t).$$ The amplitude of the resultant wave is ($$y_1$$ and $$y_2$$ are in CGS system)

A
$$5 cm$$

B
$$7 cm$$

C
$$1 cm$$

D
$$zero$$

Solution

$$y_{1}=A \sin{(\omega t)}$$
$$y_{2}=3 \sin{(\omega t)}$$
Amplitude of first wave=$$y_{1}=4=A_{1}$$
Amplitude of second wave=$$A_{2}=3$$
Resultant=$$\sqrt{(4)^{2}+(3)^{2}}=\sqrt{16+9}=5cm$$
Question 5
1 / -0

The same progressive wave is represented by two graphs $$I$$ and $$II$$. Graph $$I$$ shows how the displacement $$'y'$$ varies with the distance $$x$$ along the wave at a given time. Graph $$II$$ shoes how $$y$$ varies with time $$t$$ at a given point on the wave. The ratio measurements $$AB$$ to $$CD$$, marked on the curves, represents:

A
Wave number $$k$$

B
Wave speed $$V$$

C
Frequency $$v$$.

D
Angular frequency $$\omega$$

Solution
Question 6
1 / -0

Two $$SHM$$ are represented by equation $$x_{1}=4\ \sin (\omega t+37^{o})$$ and $$x_{2}=5\ \cos (\omega t)$$. The phase difference between them is

A
$$37^{o}$$

B
$$127^{o}$$

C
$$53^{o}$$

D
$$143^{o}$$

Solution

Given,

$$ x=A\sin (\omega t+\phi ),\,\, $$

$$ where,\,\, $$

$$ A=$$ Amplitude

$$ \phi =$$ Phase Angle

$${{x}_{1}}=4\ \sin (\omega t+{{37}^{o}})\,\ldots \ldots \,(1)$$

$${{x}_{2}}=5\ \cos \text{ }\!\!~\!\!\text{ }(\omega t)=5\sin (\omega t+{{90}^{o}})\,\ldots \ldots \,(2)$$

Phase angle difference is $${{90}^{o}}-{{37}^{o}}={{53}^{o}}$$
Question 7
1 / -0

Two sources of waves are called coherent if:-

A
Both have the same amplitude of vibrations

B
Both produce waves of the same wavelength

C
Both produce waves of the same wavelength having constant phase difference

D
Both produce waves having the same velocity

Solution

$$\textbf{Explanation:}$$ Coherent source of light are those sources which emit a light wave having the same frequency, wavelength and in the same phase or they have a constant phase difference

Hence (c) option is correct
Question 8
1 / -0

The wave number of energy emitted when electron jumps from fourth orbit to seconds orbit in hydrohen in $$20,497\ cm^{-1}$$. The wave number of energy for the same transition in $$He^{+}$$ is

A
$$5,099\ cm^{-1}$$

B
$$20,497\ cm^{-1}$$

C
$$40,994\ cm^{-1}$$

D
$$81,988\ cm^{-1}$$

Solution

Given that,

Wave number of energy for hydrogen $$=20497\,c{{m}^{-1}}$$

Now, for hydrogen

$$\dfrac{1}{{{\lambda }_{H}}}=R\left( \dfrac{1}{{{2}^{2}}}-\dfrac{1}{{{4}^{2}}} \right)=20497$$

Now, for helium

$$ \dfrac{1}{\lambda }=R\left( \dfrac{1}{{{2}^{2}}}-\dfrac{1}{{{4}^{2}}} \right)\times {{2}^{2}} $$

$$ \dfrac{1}{{{\lambda }_{He}}}=20497\times 4 $$

$$ \dfrac{1}{{{\lambda }_{He}}}=81988\,c{{m}^{-1}} $$

Hence, the wave number of energy for helium is $$81988\ cm^{-1}$$
Question 9
1 / -0

A particle is performing simple harmonic motion bout its equilibrium position $$X_0$$, then

A
$$X_0$$ must be zero

B
velocity of particle at $$X_0$$ may be zero

C
acceleration of particle at $$X_0$$ may be zero

D
acceleration of particle at $$X_0$$ must be zero

Solution

Aparticle is performing simple harmonic motion bout its equilibrium position
$$X_0$$ then
$$a=\cfrac{d^2x}{dt^2}\\ \quad=\cfrac{d^2x_0}{dt^2}$$
Due to its equilibrium position $$X_0$$ the velocity will be uniform. hence
acceleration is $$\cfrac{V_2-V_1}{t}=1=a$$
$$V_2=$$ Final velocity
$$V_1=$$ Initial velocity
$$t=$$ time internal
Question 10
1 / -0

from a line source, if amplitude of a wave at a a distance r is A, then the amplitude at a distance 4r will be

A
2A

B
A

C
A/2

D
A/4

Solution

$$\begin{array}{l} I\left( { { { intensity } } } \right) \times \frac { 1 }{ { { r^{ 2 } } } } \\ I\times { A^{ 2 } } \\ \therefore ,\, \, A\times \frac { 1 }{ r } \\ if\, \, r\to 4r,A\to \frac { A }{ 4 } \end{array}$$
