Question 1
1 / -0

Ampere's circuital law is given by:

A
$$\oint \bar{H} . \bar{dl} = \mu _0 I_{enc}$$

B
$$\oint \bar{B} . \bar{dl} = \mu _0 I_{enc}$$

C
$$\oint \bar{B} . \bar{dl} = \mu _0 I$$

D
$$\oint \bar{H} . \bar{dl} = \mu _0 I$$

Solution

The line integral of the magnetic field of induction $$\vec B$$ around any closed path in free space is equal to absolute permeability of free space $$μ_o$$ times the total current flowing through area bounded by the path.
Ampere's circuital law is given by:
$$\oint \vec B.d\vec l=\mu_0 I_{enc}$$
The correct option is B.
Question 2
1 / -0

Which of the following material is used in making the core of a moving coil galvanometer?

A
Copper

B
Nickel

C
Iron

D
Both (a) and (b).

Solution

Soft iron is used in making the core of moving coil galvanometer, because it has high initial permeability and low hysteresis loss.
Question 3
1 / -0

At a place an electric field and a magnetic field are in downward direction. There an electron moves in downward direction. Hence this electron.

A
Will bend towards left

B
Will bend towards right

C
Will gain velocity

D
Will lose velocity

Solution

When a charge enters a region where bothelectric and magnetic field exists simultaneously, Lorentz force acts on it and is given by $$\vec{F} = q[\vec{E} + (\vec{v} \times \vec{B} )]$$
Since $$\vec v$$ and $$\vec B$$ are in same direction, $$\vec V \times \vec B = vB\sin0^0 = 0$$ ,So, only electric force will act on it in upward direction $$(\vec F = -q\vec E)$$ which is in opposite direction of the velocity.Hence this electron will lose velocity.
Therefore, D is correct option.
Question 4
1 / -0

A conducting square loop of side $$L$$ and resistance $$R$$ moves in its plane with a uniform velocity $$v$$ perpendicular to one of its sides. A magnetic induction $$B$$, constant in time and space, pointing perpendicular and into the plane of the loop exists everywhere, then the current induced in the loop is

A
$$BLv/R$$ clockwise

B
$$BLv/R$$ anticlockwise

C
$$2 BLv/R$$ anticlockwise

D
$$0$$

Solution

Polarity induced $$X$$ is shown in fig.
Due to same voltage on same side no current flows.
Question 5
1 / -0

A charged particle moves through a magnetic field perpendicular to its direction. Then

A
the momentum changes but the kinetic energy is constant

B
both momentum and kinetic of the particle are not constant

C
both, momentum and kinetic energy of the particle are constant

D
kinetic energy changes but the momentum is constant

Solution
Question 6
1 / -0

Amperes circuital law is given by

A
$$\oint\bar H. \bar {dl} =\mu_0 I_{enc}$$

B
$$\oint\bar B. \bar {dl} =\mu_0 I$$

C
$$\oint\bar B. \bar {dl}=\mu_0 J$$

D
$$\oint\bar H. \bar {dl}=\mu_0 J$$

Solution

Ampere 's circuital law states that relationship between thecurrent and the magnetic field
$$\phi\overrightarrow { B } \overrightarrow { dl } =\mu_0 I$$
B is correct option
Question 7
1 / -0

An electron of energy 1800 eV describes a circular path in magnetic field of flux density 0.4 T. The radius of path is (q = 1.6 X $$10^{-19}$$ C, $$m_e$$ = 9.1 X $$10^{-31}$$ kg)

A
2.58 X $$10^{-4}$$m

B
3.58 X $$10^{-4}$$m

C
2.58 X $$10^{-3}$$m

D
3.58 X $$10^{-3}$$m

Solution

$$\displaystyle E = \frac{1}{2} mv^2 \Rightarrow v = \sqrt{ \dfrac{2E}{m} }$$
$$\displaystyle r = \frac{mv}{Be} = \frac{m}{Be} \sqrt{ \dfrac{2E}{m} } = \dfrac{\sqrt{2mE}}{Be}$$
$$\displaystyle r = \frac{\sqrt{2 \times 1800 \times 1.6 \times 10^{-19} \times 9.1 \times 10^{-31}}}{1.6 \times 10^{-19} \times 0.4} = 3.58 \times 10^{-4} m$$
Question 8
1 / -0

If an electron is moving with velocity $$\bar{v}$$ produces a magnetic field $$\bar{B}$$, then

A
the direction of field $$\bar{B}$$ will be same as the direction of velocity $$\bar{v}$$

B
the direction of field $$\bar{B}$$ will be opposite as the direction of velocity $$\bar{v}$$

C
the direction of field $$\bar{B}$$ will be perpendicular as the direction of velocity $$\bar{v}$$

D
the direction of field $$\bar{B}$$ does not depend upon the direction of velocity $$\bar{v}$$

Solution

According to Biot-Savart's law, the magnetic field
$$\displaystyle \overset{\rightarrow}{B} = \frac{\mu_o}{4 \pi} . \frac{q (\overset{\rightarrow}{v} \times \overset{\rightarrow}{r} ) }{r^3}$$
The direction of $$\overset{\rightarrow}{B}$$ will be along $$\overset{\rightarrow}{v} \times \overset{\rightarrow}{r}$$ i.e. perpendicular to the plane containing $$\overset{\rightarrow}{v}$$ and $$\overset{\rightarrow}{r}$$.
Question 9
1 / -0

Biot-Savart law indicates that the moving electrons (velocity $$\bar v$$ ) produce a magnetic field $$\bar B$$ such that:

A
$$\bar B \perp \bar v$$

B
$$\bar B \parallel \bar v$$

C
it obeys inverse cube law.

D
it is along the line joining the electron and point of observation.

Solution

Magnetic field produced by charges moving with velocity $$\bar v$$, at a distance r is $$ \bar B$$ = $$\left ( \dfrac{\mu_0}{4\pi } \right )$$.q$$\dfrac{\bar v \times \hat r}{r^2}$$
Therefore $$\bar B \perp \bar v$$
Question 10
1 / -0

Fill in the blanks
A charge is moving through a magnetic field. The force acting on the charge is maximum when the angle between the velocity of charge and the magnetic field is ______

A
$$\pi$$

B
$$\pi/3$$

C
$$\pi/2$$

D
$$\pi/4$$

Solution

We know,

$$\overrightarrow{F_B}=q\overrightarrow{v}\times\overrightarrow B=qvB\sin\theta$$
Where: $$\theta$$ = angle between v and B ,

Now for $$\overrightarrow F$$ to be maximum, $$\sin\theta$$ should be max,

i.e $$\theta =\dfrac{\pi}{2}$$

Option $$\textbf C$$ is the correct answer.
