Question 1
1 / -0

The incorrect statement of the following is:

A
Work done on a moving charge in a magnetic field is zero

B
The kinetic energy of a moving charge in magnetic field is conserved

C
Magnetic field is not produced due to electron moving in a straight line

D
Kinetic energy of a moving charge in an electric field changes

Solution

Movement of charge in a straight line results in a magnetic field being generated from the relation $$F=qvB\sin\theta$$
Question 2
1 / -0

A proton and an alpha particle are separately projected in a region , where a uniform magnetic field exists. The initial velocities are perpendicular to the direction of magnetic field . If both the particles move along circles of equal radii , the ratio of momentum of proton to alpha particle( $$\dfrac{P_p}{P_a}$$)

A
1

B
1/2

C
2

D
1/4

Solution
Question 3
1 / -0

If an electron of velocity $$(2\hat{i}+3\hat{j})$$ is subjected to magnetic field of $$4\hat{k}$$, then its:-
(a) path will change
(b) speed does not change
(c) path must be circular
(d) momentum is constant.

A
a, b

B
All

C
a, b, c

D
None

Solution

As shown, the Lorentz Force on the electron is: $$e(\vec{V} \times \vec {B})$$
In this case, it is given by:
$$e((2\hat { i } +3\hat { j } )\times 4\hat { k } )=e(3\hat { i } -8\hat { j } )$$

which shows that the force acts at some angle to the velocity.
Hence its path would change.

Also, a magnetic field always acts perpendicular to s=displacement, therefore no work is done. Hence, the change in kinetic energy is zero (Work-Energy theorem). Therefore the speed will not change.
Question 4
1 / -0

A charged particle moves in a uniform magnetic field perpendicular to it, with a radius of curvature 4 cm. On passing through a metallic sheet it looses half of its kinetic energy, then the radius of curvature of the particle is :

A
2 cm

B
4 cm

C
8 cm

D
$$2\sqrt2$$ cm

Solution

$$R= \dfrac{mv}{qB} =\dfrac{m}{qB}\sqrt{\dfrac{2(KE)}{m}}= \dfrac{\sqrt{2m}}{qB}\sqrt{KE}$$

$$\Rightarrow \dfrac{R_1}{R_2}= \dfrac{\sqrt{KE}}{\sqrt{KE/2}}$$

$$\Rightarrow R_2= \dfrac{R_1}{\sqrt2}=\dfrac{4}{\sqrt2}= 2\sqrt2cm$$
Question 5
1 / -0

The coil of a tangent galvanometer is put in the magnetic meridian

A
To avoid the magnetic effect of the earth's field

B
To produce intense magnetic field at the centre of the coil

C
To produce a field at right angle to the earth's field

D
To avoide error due to parallax

Solution
Question 6
1 / -0

The charged particles traverse identical helical paths in a completely opposite sense in a uniform magnetic field $$B={ B }_{ 0 }\hat { k }$$.

A
They have equal z-components of momenta

B
They must have equal charges

C
They necessarily represent a particle, antiparticle pair

D
The charge to mass ratio satisfy

$$\left( \dfrac{q_1}{m}\right)_{1}+\left( \dfrac{q_2}{m}\right)_{2}=0$$

Solution

As the two charged particles travers identical helical path the pitchof their helices will be same
Now pitch will be same
Now pitch $$=$$ Time for one circle completion $$\times$$ speed
$$ \Rightarrow P = T \times v\cos \theta = \dfrac{2\pi m}{qB} v\cos\theta$$ (Time period under uniform magnetic field $$= \dfrac{2\pi m}{qB})$$
As $$ P_{1}=P_{2}$$
$$ \Rightarrow \dfrac{2\pi m_{1}}{q_{1}B_{0}} v\cos \theta = \dfrac{2\pi m_{2}}{q_{2}B_{0}} v\cos\theta $$
$$ \Rightarrow \dfrac{q_{1}}{m_{1}} = \dfrac{q_{2}}{m_{2}}$$
So the have equal charge to mass eatio magnitude
But they are moving in opposite direction so one is $$+Ve$$ charge and another $$-Ve$$
$$ \Rightarrow \dfrac{q_{1}}{m_{1}} + \dfrac{q_{2}}{m_{2}} = 0 $$
Question 7
1 / -0

A positively charged particle moving with constant speed due east enters a region of uniform magnetic field directed vertically upwards this particle will-

A
Get deflected vertically upwards direction

B
move in a circular path with its increased speed

C
move in a circular path with its unchanged speed

D
Be moving in a straight part with the same speed

Solution

By right-hand rule force, $$\vec F= q\vec V \times \vec B$$ will be towards south so the charge will start moving in a circular path.
As the force is in the perpendicular direction so it will not do any work so speed will not change.
Option C is correct.
Question 8
1 / -0

A charged particle of mass 1 $$\mu $$ g and charge 1 $$\mu $$ C having speed 2m/s moves in a magnetic field 1 $$\hat{K} $$ Tesla. At a certain instant its velocity is $$\bar{V}=\hat{i}+\hat{j}+m\hat{k} $$ . The value of 'm' is ________________.

A
(1) $$\sqrt{2}$$

B
(2) 0

C
(3) 1

D
(4) Can't determine
Question 9
1 / -0

A current carrying wire and a rectangular loop are placed as shown in figure then-

A
The wire will be repelled by the rectangular loop

B
The wire will attracted by the rectangular loop

C
There will not be any change in position of wire

D
Loop will rotate

Solution

Since, there is an attractive force between $$PS$$ and the adjacent wire and the repulsive force between $$QR$$ and the adjacent wire but $$B\alpha \dfrac1{R}\implies$$ the attractive force prevails and rectangular loop is attracted to the adjacent current wire.
Question 10
1 / -0

The magnetic field strength at a point P distant r due to an infinite straight wire as shown in the figure carrying i is :

A
$$\mu_0$$

B
$$\mu_0i/ 2\sqrt2r$$

C
$$(\mu_0i/ \sqrt2 \pi r)$$

D
$$\frac{\mu_oi}{4\pi r}[2+\sqrt2]$$

Solution

We know,

Magnetic field due to semi-infinite wire,
$$B=\dfrac{\mu_0I}{4\pi R}(\cos\theta_1+\cos\theta_2)$$

$$B_1=\dfrac{\mu_0I}{4\pi R}(1+\cos(45^0))$$

$$B_2=\dfrac{\mu_0I}{4\pi R}(1+\cos(45^0))$$

$$\overrightarrow B_{net}=\overrightarrow {B_1}+ \overrightarrow{B_2}$$

$$\overrightarrow B=\dfrac{\mu_0 I}{4\pi R}(2+\sqrt 2)$$

Option $$\textbf D$$ is the correct answer.
