In this problem, we need to find the point from the option which does not lie which means the point which does not satisfy the equation of the parabola.
To find the equation of parabola:
From question, the parabola formed with the given vertex and focus on positive x axis is:

Where,
\({S}=\) Focus
\(A=\) Vertex
The general formula for horizontal parabola is:
\((y-k)^{2}=4 a(x-h)\)
Where,
\((h, k)=\) Vertex
\(a=\) Distance between vertex and focus
Now, from question, we can understand that, \((h, k)=(2,0)\)
Now, ' \(a\) ' is distance between point ' \(A\) ' and 'S'.
The distance between two points is given by the formula:
\(\mathrm{d}=\sqrt{\left(x_{2}-x_{1}\right)^{2}+\left(y_{2}-y_{1}\right)^{2}}\)
On substituting the point ' \(A\) ' and ' \(S\) ',
\(\Rightarrow a=\sqrt{(4-2)^{2}+(0-0)^{2}}\)
\(\Rightarrow a=\sqrt{(2)^{2}}\)
\(\Rightarrow a=\sqrt{4}\)
\(\therefore a=2\)
So, the equation for the given parabola is:
\(\Rightarrow(y-0)^{2}=4 \times 2(x-2)\)
\(\therefore y^{2}=8(x-2)\)
Substituting all the points given in the options:
Option (A):
\((5,2 \sqrt{6}) \Rightarrow({x}, {y})\)
On substituting the point in the obtained parabola equation:
\(\Rightarrow(2 \sqrt{6})^{2}=8(5-2)\)
\(\Rightarrow(4 \times 6)=8(3)\)
\(\Rightarrow 24=24\)
\(\therefore 24-24=0\)
This point satisfies the parabola equation.
Option (B):
\((8,6) \Rightarrow(x, y)\)
On substituting the point in the obtained parabola equation:
\(\Rightarrow(6)^{2}=8(8-2)\)
\(\Rightarrow 36=8(6)\)
\(\therefore 48-36=12\)
This point does not satisfy the parabola equation.
Option (C):
\((6,4 \sqrt{2}) \Rightarrow(x, y)\)
On substituting the point in the obtained parabola equation:
\(\Rightarrow(4 \sqrt{2})^{2}=8(6-2)\)
\(\Rightarrow(16 \times 2)=8(4)\)
\(\Rightarrow 32=32\)
\(\therefore 32-32=0\)
This point satisfies the parabola equation.
Option (D):
\((4,-4) \Rightarrow(x, y)\)
On substituting the point in the obtained parabola equation:
\(\Rightarrow(-4)^{2}=8(4-2)\)
\(\Rightarrow 16=8(2)\)
\(\Rightarrow 16=16\)
\(\therefore 16-16=0\)
This point satisfies the parabola equation.
So, the point which is not satisfying the parabola equation is in option b.
Thus, option (B) does not lie within the parabola.
