A positively charged ball hangs from a silk thread. We put a positive test charge q₀ at a point and measure F/q₀, then it can be predicted that the electric field strength E

A solid metallic sphere has a charge +3Q. Concentric with this sphere is a conducting spherical shell having charge –Q. The radius of the sphere is a and that of the spherical shell is b(b > a). What is the electric field at a distance R(a < R < b) from the centre?

If on the concentric hollow spheres of radii r and R(>r) the charge Q is distributed such that their surface densities are same then the potential at their common centre is

Two equal charges q of opposite sign separated by a distance 2a constitute an electric dipole of dipole moment p. If P is a point at a distance r from the centre of the dipole and the line joining the centre of the dipole to this point makes an angel θ with the axis of the dipole, then the potential at P is given by (r >> 2a) (where p = 2a)

A point charge q is placed at a distance a/2 directly above the centre a square of side a. The electric flux through the square is

Two identical thin rings each of radius R meters are coaxially placed at a distance R meters apart. If Q₁ coulomb and Q₂ coulomb are respectively the charges uniformly spread on the two rings, the work done in moving a charge q from the centre of one ring to that of other is

A negatively charged plate has charge density of 2 × 10^–6 C /m². The initial distance of an electronwhich is moving towards the plate, cannot strike the plate, if it is having energy of 200 eV

The charge on 500 cc of water due to protons will be
